Relative size of images maintained from original posters.
| 254 | 255 |
|---|---|
|
|
| 16 NK 150—250 Volt | 50 NK 176—250 Volt |
| 3 loop | 2x 3 loop in series, 2 side supports |
| 256 | 257 | 258 |
|---|---|---|
 |
 |
 |
| 50 NK 46—100 Volt | 25—32 NK 136—175 Volt | 5 NK 190—250 Volt 10 NK 135—250 Volt |
| 2 loop | 2 loop, central support | 4 loop, 3 central supports |
| 259 | 260 | 261 |
|---|---|---|
 |
 |
 |
| 16—25 NK 100—135 Volt | 16 NK 190—250 Volt | 16 NK 26—135 Volt |
| 2 loop, central support | 4 loop, 1 central + 2 top side supports | 2 loop, central support |
| 262 | |
|---|---|
 |
|
| 100 NK 50—250 Volt | |
| 2x 2 loop (probably in series), 2 top side supports | |
